NHP DIN-T
NHP DIN-T NLC Metal Loadcentre Surface DinT 12 Way Metal Grey
Item No. NLC12S
Product Range: NLC
Component Type (ETIM Class)
Small distribution board
Electrical
Rated current In125 A
Number of outgoing ways12
Number of poles, 18mm pitch12
Max. rated operation voltage Ue AC415 V
Rated insulation voltage Ui500 V
Neutral terminal blockYes
Neutral bar rated current100 A
Earthing terminal blockYes
Construction
Spare DIN equipment space (poles)12
DIN-railYes
Number of rows1
Material housingSteel
Material thickness1 mm
ColourGrey
Degree of protection (IP)IP30
Type of coverEscutcheon
Material thickness cover1 mm
Dimensions
Width in number of modular spacings12
Height245 mm
Width343 mm
Depth68 mm
